Luxpower Eco Beast 6Kw All-In-One Inverter

Eco Beast 6Kw Specification Sheets:

Datasheet – Eco Beast 6Kw

Eco Beast Luxpower 6Kw All-In-One Inverter

Meet the Eco Beast Luxpower 6Kw All-In-One Inverter.

Transform your home with Luxpower’s advanced inverter.

The Luxpower All-in-One Inverter, Eco Beast XBP6000 model.

• This all-in-one inverter and battery have a rated power output of 6kW and can handle a maximum PV array input of 8kW.
• Simplified installation: All the components are already integrated into a single unit.
• Scalable Design: 5.12kWh or 10.24kWh Option. The system can be expanded to meet your needs as they grow.
• Reduced cost: All-in-one inverters can sometimes be less expensive than purchasing separate components.
• Compact size: typically smaller than their component counterparts.

6Kw All-In-One Battery Module

• Battery Power: 5.12kWh.
• Rated Voltage: 51.2V.
• Rated Capacity: 100Ah.
• Battery Type: Lithium-ion.
• Max. Parallel (Default): 2pcs.
• Max. Discharging Current: 100A.
• Max. Charging Current: 100A.
• Dimension (D*W*H): 165*580*434 mm.
• Net Weight: TBD.
• Standard: UN38.3, CE.

All-In-One Inverter Module: XBP6000
Input (PV DC)

• Max. PV Array Power (W): 8000(4000/4000).
• Rated pV Input Voltage: 320V.
• Number of Independent MPPT Inputs: 2.
• PV Input Voltage Range: 100-480V.
• MPPT Voltage Range: 120-385V.
• Start-up Voltage: 100V.
• Max. PV Input Current per MPPT: 17/17A.
• Max. Py Short-circuit Current per MPPT: 5/25A.
• Max. PV Charging Current: 125A.

Battery Input.

• Battery Voltage: 38.4-60V.
• Charging/Discharging Current: 125/140A.
• Charging/Discharging Power: 6000W.
• UPS output @ Off-Grid.
• Waveform: Pure sine wave.
• Voltage Regulation (V): 208/220/230/240.
• Frequency: 50/60Hz.
• Power: 6000W.
• Current: 26.5A.
• Peak Efficiency: 93%.
• Surge Power: 2*Pn, 5s.
• 3-+0
• Parallel Quantity: 16PCS.

AC Input.

• Voltage: 230V.
• Frequency: 50/60Hz (Auto detection).
• Current: 39.5A.
• Power: 9000W.
• Charging Current: 125A.

AC Output @Gird.

• Current: 26.5A.
• Power: 6000W.
• Bypass Relays: 60A.
• Generator Input.
• Voltage: 220/230/240V.
• RFrequency: 50/60Hz.
• Input Current: 32A.
• Input Power: 7370W.
• The current of Bypass Relays: 60A.
• Protection/General Specifications.
• Grid Monitoring: YES.

Overall, a Luxpower all-in-one inverter can be a practical solution for combating load shedding, offering convenience, backup power, and improved power quality.
